FACTOR:
|
||||
Rated input (BTU/hr)
|
40,000
|
117,000
|
117,000
|
125,000 LP 130,000 NG
|
Minimum input (BTU/hr) |
20,000
|
33,000
|
33,000
|
28,000
|
Maximum Flow Rate (GPM) |
1.3
|
4.0
|
4.0
|
-
|
Minimum Flow Rate (GPM) |
0.6
|
0.5
|
0.5
|
-
|
Hot Water Output (GPM): |
|
|
|
|
(a) 45? rise (F) |
1.3
|
1.0 - 4.0
|
1.0 - 4.0
|
1.0 - 5.0
|
(b) 100? rise (F) |
0.6
|
0.5 - 1.8
|
0.5 - 1.8
|
0.5 - 2.5
|
Flue Size: |
4"
|
5"
|
5"
|
4" PV
|
Water Inlet (NPT) |
1/2
|
1/2
|
1/2
|
1/2
|
Water Outlet (NPT) |
1/2
|
1/2
|
1/2
|
1/2
|
Gas Inlet (NPT) |
1/2
|
1/2
|
1/2
|
1/2
|
Overall Size:
|
|
|
|
|
Height |
25 3/8
|
30 5/16
|
30 5/16
|
30 5/16
|
Width |
10 5/8
|
17 5/16
|
17 5/16
|
18 1/4
|
Depth |
9 1/8
|
8 11/16
|
8 11/16
|
8 3/4
|
Shipping Weight |
25lbs
|
44lbs
|
44lbs
|
45lbs
|
Gas Consumption:
|
|
|
|
|
LP-GAS (lbs./hr.) |
0.9 - 1.85
|
1.5 - 5.4
|
1.5 - 5.4
|
1.5 - 5.8
|
NAT GAS (Cu.F./Hr.) |
18.6 - 37.0
|
30.6 - 108.8
|
30.6 - 108.8
|
30.6 - 121
|
Inlet Water Pressure:
|
|
|
|
|
Min. pressure for showers |
40
|
40
|
40
|
40
|
Min. working pressure (PSI) |
13
|
13
|
13
|
13
|
Max. working pressure (PSI) |
150
|
150
|
150
|
150
|
Gas Inlet Pressure Requirements:
|
|
|
|
|
LP-GAS |
11
|
11
|
11
|
11
|
NAT.GAS |
7
|
7
|
7
|
7
|
Efficiencies:
|
|
|
|
|
Thermal |
81%
|
82%
|
82%
|
82%
|
Energy Factor (E.F.) |
N/A
|
.69
|
.80
|
.78
|
